Features
- Full-screen display function
- Measurement point
- Echo-echo thickness measurement
- Peak memory
- Automatic gain
- Alarm function
- Solid waveform display
Technical Specifications
| Working frequency | 0.5 MHz to 15 MHz |
| Material sound velocity | 3,280.84 in/s to 32,805.19 in/s(1000 m/s to 9999 m/s) |
| Work way | Pulse echo, twin crystal |
| Pulse shift | 0 in to 78.74 in(0 mm to 2000 mm) |
| Probe zero | 0 us to 99.99 us |
| Gain adjustment | 0 dB to 110 dB,(0.1 dB,1 dB, 2 dB, 6 dB) |
| Vertical linear error | ≤ 3% |
| Horizontal linear error | ≤ 0.3% |
| Resolution | ≥32 dB |
| Dynamic Range | ≥ 30 dB |
| Sensitivity margin | ≥ 55 dB (depth 7.87 in (200 mm) Φ 2) |
| Average electrical noise level | ≤ 10% |
| Battery working time | > 8 hr |
| power source | 12 V DC, 220 V AC |
| Dimension | 10.63 in x 7.84 in x 2.36(270 mm x 190 mm x 60 mm) |
| Weight | 4.41 lb (2 Kg) |
