| Measure Parameters |
Refractive index(nD), Brix (%), Temperature (° C) |
| Measure range |
0% to 15%, 0% to 33%, 0% to 53%, 93% |
| Min Resolution Ratio: |
Brix: 0.1% (Range for 15%, 33% & 53%), Brix: 0.5% (Range for 93%) |
| Measurement Accuracy |
Brix: ±0.1%, Brix: ±0.3% (standard) |
| Operating current |
≤200 mA |
| Display menu |
Refractive index(nD), Brix (%), Temperature (° C) |
| Output |
4 mA to 20 mA, 4 mA to 20 mA + RS485 optional |
| Power |
12 V to 24 V DC |
| Wetted parts material |
Prism: sapphire, Prism stage: SS304, SS316L |
| Optical source |
LED (the wavelength approximately to D line) |
| Max Pressure |
1 MPa |
| Protection grade |
IP67 |
| Process connection |
3” tri-clam, other size supply free adaptor |
| High and low limit settings |
Buttons can be set |
| Recorder output cable |
2 M,3 M,5 M,10 M optional |
| Temperature sensor |
Thin film platinum sensor |
| Measurement Temperature |
32 °F to 185 °F (0 °C to 85 °C) |
| Environment Temperature |
32 °F to 104 °F (0° C to 40° C) |
| Weight |
11.02 lb (5 kg) |
