| Optical Geometry |
Reflect: di: 8 °, de: 8 ° (diffused illumination, 8-degree viewing angle) |
| Integrating Sphere Size |
1.89 in (48 mm) |
| Light Source |
Combined LED Light, UV Light |
| Spectrophotometric Mode |
Concave Grating |
| Sensor |
256 Image Element Double Array CMOS Image Sensor |
| Wavelength Range |
400 nm to 700 nm |
| Wavelength Interval |
10 nm |
| Semi band Width |
10 nm |
| Measuring Time |
1.5s |
| Repeatability (Spectral Reflectance) |
MAV / SCI: within 0.08 %, 400 nm to 700 nm: within 0.18 % |
| Chromaticity Value |
MAV / SCI: within ΔE x ab 0.03 (After calibration, measure the averagevalue of the whiteboard 30 times each 5 s) |
| Inter-instrument Agreement |
MAV/SCI: within ΔE x ab 0.15 (Average value for 12 BCRA series II color tiles) |
| Measurement Mode |
Single measurement, average measurement (2 to 99 times) |
| Locating Method |
Camera Locating |
| Battery |
Li-ion battery. 5000 measurements within 8 h |
| Illuminant Life Span |
5 years, more than 3 million times measurements |
| Display |
TFT color LCD, Capacitive Touch Screen |
| Interface |
USB / RS-232, Bluetooth® 4.0 dual mode (compatible with 2.1) |
| Data Storage |
Standard 1000 Pcs, Sample 28000 Pcs |
| Operating Environment |
85 % RH (no condensing), Altitude < 2000 m |
| Storage Environment |
85 % RH (no condensing) |
| Standard Accessory |
Power Adapter, Built-In Li-ion Battery, User Guide, PC Software, White and Black Calibration Cavity, Dust Cover |
| Optional Accessory |
Micro Printer, Powder Test Box (M1cro Printer) |
| Dimension |
L x W x H = 7.24 in x 3.03 in x 4.13 in (184 mm x 77 mm x 105 mm) |
| Weight |
1.32 lb. (0.6 kg) |
