| OpenEYE Equalization |
You can probe anywhere on the bus thanks to OpenEYE Technology with automatic tuning equalization circuitry |
| ScopePHY Probing |
Quickly gain confidence that your setup is correct and your PCI signal meets probe input requirements by routing any signal directly to a high bandwidth Oscilloscope |
| FastSYNC |
Guaranteed resynchronization time to be <12 FTS1 (PCIe2) or <4 FTS2 (PCIe3) regardless of the Electrical Idle time for Advanced Power State Management performance |
| Data Storage and HW Accelerated Search |
Get access to data and execute searches on any pattern in seconds regardless of record length |
| Comprehensive Trigger System |
Quickly build a trigger definition to trigger on the most elusive PCIe events occurring on Link |
| Innovative Data Views |
Get unprecedented visibility into your data from Protocol to Physical layer
- Observe and Analyze Link based behavior of protocol elements (transactions, packets, fields, ordered sets) with the Transaction Window
- Get high-ground visibility of system issues involving flow control with Unique Bird’s EyE Viewintegrated into the Transaction window
- Get a data rich statistic based view of all PCIe protocol elements through summary Profile Window
- Get insight into physical layer details with the unique Listing window showing packet details as well as lane by lane symbol decode
|
| MultiBus Correlation |
Get full system visibility of multiple busses (DDR, PCIe, QPI, etc.) as well as other system level activity through the legacy power of the Logic Analyzer functionality |
