Overview
Emissions and Stack medical laboratory colorimeter is designed for simple operation with durable function and permit speedy accurate measurement in routine analysis. The optical system consists of the lamp, hear-absorption filter, lens and diaphragm. The light traversing in this system falls on the current generating photocell which actuates a direct reading microammeter or LED display.
Technical Specifications
| Economy | Consumes only 1.5 ml of reagent |
| Economy | Silicon photocell |
| Wavelength Range | 420 nm to 660 nm |
| Photoelectric Range | T% 0% to 100%, ABS log TO-2 |
| Photoelectric Accuracy | 2 T |
| Light Source | 6 V 0.5 A tungsten lamp |
| Power Supply | 110 V or 220 V AC 10 W |
| Dimension | 11 in x 8.6 in x 4.8 in (280 mm x 220 mm x 122 mm) |
| Weight | 6.6 lb (3 kg) (body only) |
