Technical Specifications
| Measuring Range | 0.03 in to 472.44 in (1.0 mm to 12000 mm) |
| Resolution | 0.00 in (0.01 mm) (<100 mm) 0.03 in (1 mm) (>100 mm) |
| Velocity | 500 m/s to 20000 m/s |
| Delay | -20 µs to 3400 µs /resolution: 0.1 µs |
| Probe Delay | 0 µs to 99 µs /resolution: 0.01 µs |
| Horizontal Error | ≤0.1% Vertical error≤3% |
| Dynamic Range | ≥36 db |
| Sensitivity | ≥64 db 7.87 in (200 mm) 2 flat-bottomed hole |
| Humidity | 5% to 90% |
| Input | 100 V to 240 V or 50 Hz to 60 Hz |
| Output | 9 v dc / 4 a |
| Temperature | -4 °F to 158 °F (-20 ℃ to 70 ℃) |
| Dimension (mm) | 9.44 in × 7.08 in × 1.96 in (240 mm × 180 mm × 50 mm) |
| Weight | 4.18 lbs (1.9 Kg) |
