Overview
Emissions And Stack multifunctional signal generator can measure or output multiple signals including voltage, current, TC, with LCD screen, silicone keyboard, simple operation, longer standby time, higher accuracy, and programmable output. It is widely used in labs, industry local, PLC, process instruments, electric valve and many other area’s debugging.
Features
- Measurement signal interface
- LCD display
- Battery indicator
- Signal output interface
- Measurement and output debugging button
Technical Specifications
| Voltage Signal | 0 V to 30 V, 0 V to 25 mV or 0 mV to 100 mV |
| Current Signal | 0 mA to 25 mA, 4 mA to 20 mA |
| Output signal | 0 mA to 24 mA or 0 V to 12 V |
| Power supply | 220 V AC |
| Accuracy | 0.05%, 0.02% |
| Frequency range | 100 kHz to 150 MHz |
| Thermal Couple | K, E, J, T, R, B, S |
| Operating Temperature | 14 ℉ to 131 ℉ (-10 ℃ to 55 ℃) |
| Storage Temperature | -4 ℉ to 158 ℉ (-20 ℃ to 70 ℃) |
| Size | 11.4 in x 8.7 in x 7.1 in (290 mm x 220 mm x 180 mm) |
| Weight | 2.20 Ib (1 kg) |
