Technical specification
| Standard Wavelength | 1310nm or 1550 nm |
| Dynamic Range | 35 dB or 33 db |
| Event Dead Zone | 2.6 ft (0.8 m) |
| Attenuation Dead Zone | 19.7 ft (6 m) |
| Ranging Accuracy | ± (3.3 ft or 1m) +Sampling interval+0.005%x Distance) Does not include refractive index placement error |
| Highest Range Resolution | 1.6 ft (0.05 m) |
| Test Pulse Width | 5 ns,10 ns,30 ns,100 ns,275 ns,500 ns,1000 ns ,5000 ns,10000 ns,20000 ns |
| Loss Threshold | 0.01 db |
| Sampling Points | 128 k |
| Linearity | 0.05 dB or dB |
| Loss Resolution | 0.001 dB |
| Waveform Storage Capacity | ≥1000 |
| External Interface | USB, Min-USB, RJ-45 |
| Optical Output Interface | FC |
| VFL | 650 nm±10 nm, ≥5 mw |
| Optical Power Meter | Wavelength range: 1200 nm to 1650 nm; Power range: -45 dBm to +26 dBm |
| Stable Light Source Function | 1310 nm to 1550 nm: -5 dBm CW (270 Hz, 1K270 Hz, 2K270 Hz) |
| Display | 5.8 in (14.7 cm) color TFL-LCD touch screen |
| Battery | 7.4 v or 5000 mAh Li-on battery, Max 12 hours |
| Power Supply | Put out: 19 V. 1.31 A |
| Adapt To the Environment | Operating temperature: 23 °F to 122 °F (-5 ℃ to 50℃) Storage temperature: −4 °F to 158 °F (-20 ℃ to 70 ℃)Relative humidity 0% to 95% No condensation |
| Size | 8.5 in x 5.9 in x 2.8 in (215 mm x 150 mm x 70 mm) |
| Weight | 3.30 lb (<1.5 kg) |
