Overview
Emissions And Stack optical spectrum is a light weight and high-cost performance of portable spectrum analyser. The realization of the digital intermediate frequency to ensure its excellent performance and stable performance. Original widescreen application, novel appearance for education, research and development, production test and other industries to provide an alternative.
Features
- The digital intermediate frequency technology
- 9 kHz to 1.5 GHz frequency range
- Shows the average noise level (DANL) – 135 dBm (typical)
- Phase noise – 80 dB c per Hz (offset 10 kHz)
- Whole range accuracy <1.5 dB
- Minimum resolution bandwidth (RBW) 100 Hz
- The standard preamplifier
- 5 GHz tracking source (DSA815 – TG)
- Equipped with abundant advanced measurement function
- Equipped with EMI (electromagnetic interference) filter and peak detector
- Pattern matching VSWR measurement suite
- Rich interface: LAN (Local Area Network)
Technical Specification
| Display | 0.083 ft (8-inch) WVGA |
| Frequency Range | 9 kHz to 1.5 GHz |
| DANL (Displayed Average Noise Level) | -135 dBm, typical |
| Phase Noise | 00 dB c per Hz to 10 kHz offset, typical |
| Total Amplitude Accuracy | 2% |
| Minimum Wavelength | Not specified |
| Dynamic Range Maximum Level | Not specified (please clarify) |
| Interfaces | USB host & device, LAN, GPIB (optional), 10 MHz REF In, 10 MHz REF Out, External Trigger In |
| Trigger Source | Free Run, Video, External |
| External Trigger Level | SV TTL Level |
| Dimensions | 14.2 in. x 7 in. x 5 in. (361.6 mm x 178.8 mm x 128 mm) |
| Weight | 9.36 lb (4.25 kg) |
