Overview
Emissions and Stack paper industrial colorimeter, is designed for measuring the whiteness of objects. Widely applied in papermaking, printing, textile printing and dyeing, building materials, chemical, food, salt, and other industries, as well as production and commodity inspection departments requiring precise whiteness measurements. Elevate your colour analysis capabilities with the ideal instrument for assessing whiteness in various applications.
Features
- Advanced circuit design ensures accuracy
- Power-off protection for calibration data
- Standard this product interface for PC communication
Technical Specifications
| Power supply | AC (100 to 240) V (50 or 60) Hz, 50 W |
| Display | 128 x 32 dot matrix LCD screen |
| Light source | Analog D65 |
| Integrating sphere | Diameter 5.90 in (150 mm) |
| Sample size | Test plate diameter ≥φ30 mm (1.18 in) while sample thickness ≤ 40 mm (1.57 in) |
| Zero drift | ≤ 0.1 |
| Indicating drift | ≤ 0.5 |
| Repetitive accuracy | ≤ 0.02 (10 consecutive tests at intervals of 10 seconds) |
| Specular reflectance accuracy | ≤ 0.1 |
| Communication interface | RS232 (optional) |
| Working environment | Temperature 50 ℉ to 95 ℉ (10 ℃ to 35 ℃) |
| Dimension | 14.37 in x 10.23 in x 16.73 in (365 mm × 260 mm × 425 mm) |
| Net weight | 26.45 lb (12 kg) |
