Overview
Emissions and Stack portable colorimeter has adopted multi-channel color sensors of international brands, more stable IC platform as well as efficient and accurate algorithms to provide users with accurate and fast color management and application
Features
- Humanity Design, Convenient Operation
- Stable Measurement Performance
- Convenient Fast Locating Function
- Expandable PC Software Features
- Advanced Power Management Design
Technical Specifications Top of Form
| Illuminating/Viewing Geometry | 8/d |
| Measuring Aperture | Φ 0.31 in (787.4 mm) |
| Detector | Silicon photoelectric diode |
| Light Source | D65 |
| Light Source Device | LED blue light excitation |
| Storage | 100 pcs standards 20000 pcs samples |
| Repeatability | Standard deviation within ΔE x ab 0.07
Average of 30 measurements of standard white plate |
| Power source | Rechargeable lithium-ion battery 3.7 V @3200 mAh |
| Lamp Life | 5 years, more than 1.6 million measurements |
| Charging Time | 2 hrs. (first time 8 hours– 100% electricity) |
| Measurement Times Before Recharging | More than 3000 times |
| Operating Temperature/Humidity Range | 14 ℉ to 104 ℉ (-10 ℃ to 40 ℃) relative humidity 0 to 85% with no condensation |
| Data Interface | USB |
| Printer (optional) | Miniature thermal printer |
| Weight | 1.10 lb. (500 g) |
| Dimension | 8.07 in x 2.8in x 3.9 in (205 mm × 70 mm × 100 mm) |
