Overview
Emissions and Stack radio flaw detectors are essential for detecting pipelines (oil, gas, water, etc.) and cables (electricity, telecommunication) used by organizations in pipeline management, municipal planning, and construction. It’s a modern alternative to traditional detectors.
Features
- Adoption of DSP processors, having a higher calculation speed and accuracy
- The orientation function available to indicate the pipeline running, making location faster
- The 10 W broadband transmitter used, applicable to various environments
- The Lithium battery pack used to supply power for both the receiver and the transmitter being energy-efficient and environmental-friendly
Technical Specifications
| Output modes | induction, direct link, clamping |
| Working Frequencies | 128 Hz, 512 Hz, 1 KHz, 2 KHz, 8 KHz, 33 KHz, 65 KHz, 83 KHz |
| Induction mode | 65 KHz, 83 KHz |
| Direct link mode | 128 Hz, 512 Hz, 1 KHz, 2 KHz, 8 KHz, 33 KHz, 65 KHz, 83 KHz |
| Clamping mode | 33 KHz |
| Maximum power output | 10 W |
| Maximum current output | 1 A |
| Maximum voltage output | 60 V |
| Power supply | dual power supply, Lithium battery pack (energy-efficient and environmental-friendly) |
| Continuous working time | 1 W 12 hrs
5 W 8 hrs 10 W 5 hrs |
| Ambient temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Weight | 5.73 lb (2.6 kg) |
