Features
- Supports 9.95 Gb / s to 11.3 Gb / s bit rates
- Hot-Pluggable
- Single LC for Bi-directional Transmission
- cooled EML transmitter, APD photo-detector
- 2-wire interface compliant with SFF 8472 for management specs and diagnostics
- Power Supply: +3.3 V
- Power consumption <3 W
- RoHS compliant
Technical Specifications
| Data Rate | 10G |
| TX Power | 1 dBm to 5 dBm |
| Receiver Sensitivity | <-25 dBm |
| Distance | 62.14 mi (100 km) |
| Wavelength | 1490 nm or 1550 nm |
| Temperature | 32 °F to 158 °F (0 °C to 70 °C) |
| Single package size | 7.87 in x 5.90 in x 1.96 in (200 mm x 150 mm x 50 mm) |
| Single gross weight | 4.40 lb (2 kg) |
