Features
- Dual data – rate of 1.25 Gbps or 1.063 Gbps operation
- 1310 nm FP or 1490 nm or 1550 nm DFB laser
- PIN photo detector for 12.42 miles (20 km) transmission
- Compliant with SFP MSA and SFF – 8472
- Simplex LC or SC receptacle
- Digital Diagnostic Monitoring Internal Calibration or External Calibration
- Compatible with SONET OC – 24 – LR – 1
- Compatible with ROHS
- +3.3 V single power supply
- Operating case temperature Standard 32 °F to 158 °F (0 °C to +70 °C)
Technical Specifications
| Use | FTTX |
| Network | None |
| Wavelength | 1550 nm TX or 1310 nm RX |
| Function | DDM |
| Data rate | 1.25 Gbps |
| Connector | LC |
| Distance | 12.42 mi (20 km) |
| Power supply | 3.3 V |
| Operating temperature | 32 °F to 158 °F (0 °C to +70 °C) |
