Technical Specifications
| Wavelength | 1310 nm |
| Distance | 10 km |
| Power supply | 3.3 V |
| Data Rate | 10 Gb/ s |
| Supply current | 430 mA |
| Power Consumption | 1.5 W |
| Input differential impedance | 100 Ω |
| Tx input single ended DC Voltage Tolerance | -0.3 V to 4 V |
| Differential input voltage swing | 180 mV to 700 mV |
| Disable voltage | 2 V |
| Rx Output Diff Voltage | 300 mV to 850 mV |
| Rx Output Rise and Fall time | 30 ps |
| LOS Fault | 2 V |
| Temperature | -40 ºF to 185 ºF (-40 ºC to 85 ºC) |
| Size | 58 mm x 13 mm x 6.3 mm (2.2 in x 0.5 in x 0.24 in) |
