Overview
Emissions And Stack SFP+ Transceiver are designed for single fiber bi-directional serial optical data communications up to 11.3 Gb/ s. The electrical interface is compliant with SFI specifications of SFF – 8431. The transceiver consists of DFB optical transmitter and PIN receiver, and transmission distance up to 80 Km on single mode fiber. SFP+ offers commercial and industrial operating temperature options.
Features
- Electrical interface specifications per SFF – 8431
- Management interface specifications per SFF – 8431 and SFF – 8472
- SFP+ MSA package with Single LC receptacle
- DFB Laser, PIN photodetector
- Up to 11.3 G data links
- Single 3.3 V power supply
- Class 1 laser safety certified
- Operating temperature Options (Commercial) 32 ºF to 158 ºF (0 ℃ to 7
- 0 ℃), (Industrial) -40 ºF to 185 ºF (-40 ºC to 85 ºC)
- Up to 40 km on 9/ 125 µm SMF
- RoHS6 Compliant
Technical Specifications
| Data Rate | 10 G |
| Fiber | SM/ MM |
| Distance | 300m/1km/10km/40km/80km |
| Wavelength | 1270NM ~ 1610NM |
| Power supply | 3.3 V |
| Data Link | 11.3 G |
| Temperature | 32 ºF to 158 ºF (0 ℃ to 70 ℃)-40 ºF to 185 ºF (-40 ºC to 85 ºC) |
