Overview
Emissions And Stack SFP Transceiver Module are high-performance, cost-effective modules supporting data-rate of 155 Mbps and 20 km transmission distance with SMF. The transceiver consists of three sections an FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF – 8472. For further information, please refer to SFP MSA.
Features
- Data Rate Up to 155 Mbps bi-directional data links
- Wavelength HL – SB3515 – 20 LCD Tx 1310 nm, Rx 1550 nm
HL – SB5315 – 20 LCD Tx 1550 nm, Rx 1310 nm
Distance 20 km - Compliant with SFP MSA and SFF – 8472 with single LC receptacle
- Digital Diagnostic Monitoring: Internal Calibration or External Calibration
- Compatible with RoHS
- 3 V single power supply
- Operating case temperature:
- Standard 32 ºF to 158 ºF (0 ºC to 70 ºC)
- Industrial -40 ºF to 185 ºF (-40 ºC to 85 ºC)
Technical Specifications
| Power supply voltage | 3.3 V to 3.45 V |
| Transmitter Rate | 155 Mbps |
| Receiver Rate | 155 Mbps |
| Supply current | 300 mA |
| Power Loss | 1000 mW |
| Wavelength | 1300 nm to 1320 nm |
| Transmitter Power | -7.5 dB to -3 dB |
| Maximum Receiver Power | -1 dBm |
| Receiver Sensitivity | -28 dBm |
| Storage Temperature | -40 ºF to 185 ºF (-40 ºC to 85 ºC) |
