Features
- Supports 9.95 Gb/s to 11.3 Gb/s bit rates
- Monolithically integrated full C-band tunable transmitter and APD receiver
- 50 GHz ITU channel spacing with integrated wavelength locker
- Maximum link length of 49.70 mi (80 km)
- Metal enclosure, for lower EMI
- 2-wire interface with integrated Digital Diagnostic monitoring
- Hot-pluggable SFP+ footprint
- Specifications compliant with SFF-8472 V10.3 & SFF-8690 V1.4
- Compliant with SFP+ MSA with LC connector
- Power dissipation <1.65 W
- Case temperature range: 23 °F to 158 °F (-5 °C to 70 °C)
Technical Specifications
| Connector | LC |
| Data rate | 10 G |
| Use | FTTH FTTX |
| Wavelength | DWDM Tunable |
| Voltage supply | 3.3 V |
| Distance | 49.70 mi (80 km) |
| Case temperature range | 23 °F to 158 °F (-5 °C to 70 °C) |
