Features
- Up to 100 Gbps Data Links
- Up to 49.71 mi (80 km) transmission on SMF
- Power dissipation <1.5 W
- 1270 nm DFB laser and PIN receiver for LASX-T2733S-ER
- 1330 nm DFB laser and PIN receiver for LASX-T3327S-ER
- 2-wire interface with integrated Digital Diagnostic monitoring
- EEPROM with Serial ID Functionality
- Hot-pluggable SFP+ footprint
- Compliant with SFP+ MSA with LC connector
- Single 3.3 V Power Supply
- Case operating temperature 32 ℉ to 158 ℉ (0 ℃ to 70 ℃)
Technical Specifications
| SFP | Small Form-Factor Pluggable |
| Power dissipation | <1.5 W |
| Data Rate | 1.25 G, 10 G, 25 G, 40 G, 100 G |
| Wavelength | 1270 nm, 1310 nm, 1490 nm, 1550 nm |
| Distance | 6.21 mi, 12.43 mi, 49.71 mi, 99.42 mi(10 km, 20 km, 80 km, 160 km) |
| Connector Type | Duplex LC |
| Fiber Type | SMF |
| DDM | Available |
| Status | Active |
| Voltage | 3.3 V |
| Operating Temperature | 32 ℉ to 158 ℉ (0 ℃ to 70 ℃) |
