Features
- Supports 9.95 Gb/s to 11.3 Gb/s bit rates
- Monolithically integrated full C-band tunable transmitter and APD receiver
- 50 GHz ITU channel spacing with integrated wavelength locker
- Up to 49.71 mi (80 km) on 9 µm or 125 µm SMF
- Hot-pluggable SFP+ footprint
- Compliant with SFP+ MSA with LC connector
- Metal enclosure, for lower EMI
- RoHS compliant and lead-free
- Support Digital Diagnostic Monitoring interface
- Specifications compliant with SFF-8472 V 11.3 & SFF-8690 V 1.4
- Single 3.3 V power supply
- Case operating temperature
Technical Specifications
| Optical Wavelength | -0.05 nm to 0.05 nm |
| Center Wavelength Spacing | 50 GHz Typ. |
| Optical Spectral Width | 1 nm Max. |
| Side Mode Suppression Ratio | 35 dB Min. |
| Average Optical Power | -1 dBm to 4 dBm |
| Optical Extinction Ratio | 8.2 dB Min. |
| Transmitter and Dispersion Penalty | 3 dB Max. |
| Transmitter off Output power | -30 dBm Max. |
| Frequency stability (BOL) | 1.5 GHz Max. |
| Frequency stability (EOL) | 2.5 GHz Max. |
| Transmitter Eye Mask | Compliant with IEEE 802.3 ae |
| Center Wavelength | 1270 nm to 1610 nm |
| Receiver Sensitivity (Average power) | -23 dBm Max. |
| Input Saturation Power (overload) | -6 dBm Min. |
| LOS Assert | -36 dB Min. |
| LOS De-assert | -27 dBm Max. |
| LOS Hysteresis | 0.5 dBm Min. |
| Data Rate | 10.3125 Gb/s |
| Transmission Distance | 49.71 mi (80 km) SMF |
| Temperature (Operating Case) | 32 ℉ to 158 ℉ (0 ℃ to 70 ℃) (commercial) |
