Features
- Two wavelengths: 1310 nm / 1550 nm
- Touching screen (Optional)
- Test record can be saved
- Optical power meter/ optical light source/ visual fault locator/
- OTDR- -Multi-function tester
- Editable file name and line
- Support upgrade
- 4-inch ISP Display, 800 x 480 pixels, Clear and readable in outdoor sunlight
- Quick boot, it takes only 2 seconds to test
Technical Specifications
| Wavelength | 1310 nm / 1550 nm |
| Dynamic Range | 22 dB / 20 dB |
| Measure Distances | Up to 2362000 in (60 km) |
| Fiber Type | SM |
| Type of FiberĀ | 9 um/125 um single module optic fiber |
| Connector Type | FCPC SCPC |
| Peak value of laser | > 30 mw |
| Weight | 2.2 lb (1 kg) |
| number of test record saved | 100 |
| Battery working timeĀ | > 5000 times |
| Humidity | 0% to 85% |
