Overview
This Surface Roughness Tester has driving trip of upto 0.7 in, data storage of 100 groups, 20 hours of working time and ± 10% error indication
Feature
- Electromechanical integration design, small volume, light weight, easy to use
- Using DPS to control and data processing, high speed, low power consumption
- Large range parameters
- Display information rich, intuitive, can display all graphics
- Built in rechargeable lithium battery and a charging control circuit
- Working time more than 20 hrs
- Reliable control motor and software design
- Measurement information display and menu prompt information
- Can be in English freely switch
- Can be connected to a computer and printer
- Optional sensor surface, hole sensor, hole sensor, measuring platforms and sensor
Technical Specifications
| The maximum driving trip | 0.7 in (17.5 mm) |
| Filter | RC, PCRC, Gauss, ISO13565 |
| The sampling length L | 0.01 in, 0.03 in, 0.1 in, 0.3 in (0.25 mm, 0.8 mm, 2.5 mm, 8 mm) |
| Internal storage capacity | 100 groups of original data |
| External input / output interface | USB |
| The measured profile | Roughness, waviness, the original contour |
| Indicating error | Not more than ± 10% |
| Variation of indication | Not more than 6% |
| Single package size | 15.7 in x 11.8 in x 7.9 in (40 cm x 30 cm x 20 cm) |
| Single gross weight | 17.63 lb (8 Kg) |
