Features
- 2 channels, wide vertical range: 1 mV/div to 20 V/div
- 7 in (17.78 cm) widescreen LCD display
- The new interface styles
- Plug-and-Play USB Storage Support
- USB Communication and Remote Control with Computer
- USB drive system software upgrade
- Storage of waveform setups and interface waveform and setup reproduction
- Automatic measurement of 32 waveform parameters
- Unique waveform record and replay function
- Multilingual menu available
Technical Specifications
| Channels | 2 |
| Bandwidth | 100 MHz |
| Sample Rate | 1 GS/s |
| Rise Time | ≤3.5 ns |
| Memory Depth | 25 kpts |
| Waveform Acquisition Rate | ≥2000 wfms/s |
| Vertical Sensitivity (V/div) | 1 mV/div to 20 V/div |
| Time base Range (s/div) | 2 ns/div to 50 s/div |
| Storage | Setup, Wave, Bitmap |
| Trigger Modes | Edge, Pulse, Video, Slope, Alternate |
| Interface | USB OTG |
| Power | 100 VACS to 240 VAC, 45 Hz to 440 Hz |
| Display | 7 in (17.78 cm) 64K Colour TFT LCD, 800 pixels × 480 pixels |
| Product Size (W × H × D) | 12.05 in x 5.79 in x 4.80 in (306 mm × 147 mm × 122 mm) |
| Weight | 4.85 lb (2.2 kg) |
