Overview
Emissions And Stack tunable SFP+ transceiver supports up to 49.70 mi (80 km) link lengths over single-mode fiber (SMF) via an LC duplex connector. This transceiver is compliant with SFF-8431, SFF-8432, SFF-8690 and ITU-T G.698.1 standards. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, to allow access to real-time operating parameters.
Technical Specification
| Max Data Rate | 10 Gbps |
| Max Cable Distance | 49.70 mi (80 Km) / Powerbudget 23 dB |
| Wavelength | C17 to C61 DWDM 50 GHz Tunable, Total 89 Channel |
| Output Power | -1 dBm to 3 dBm |
| Receiver Sensitivity | <-22 dBm |
| Temperature Range | 32 °F to 158°F (0 °C to 70 °C) |
