Features
- Supports 9.95 Gb/ s to 11.3 Gb/ s bit rates
- Monolithically integrated full C-band tunable transmitter and APD receiver
- 50 GHz ITU channel spacing with integrated wavelength locker
- Up to 80 km on 9/ 125 µm SMF
- Support Digital Diagnostic Monitoring interface
- Hot-pluggable XFP footprint
- No Reference Clock required
- Metal enclosure, for lower EMI
- RoHS compliant and lead-free
- Supports Line-side and XFI loopback
- Standard bail release mechanism
- Single 3.3 V power supply
- Power dissipation <3.5 W
- Case operating temperature Commercial 32 ºF to 158 ºF (0 ºC to 70 ºC)
Technical Specifications
| Data Rate | 10.3 G |
| Transmission distance | 80 km |
| Power supply | 3.3 V |
| Power dissipation | 3.5 W |
| Receiver sensitivity | -24 db |
| Input Power | -7 db |
| Power consumption | 3.5 W |
| Temperature | 32 ºF to 158 ºF (0 ºC to 70 ºC) |
