Features
- Automated calibration of transducer Zero Offset and Velocity
- Automated gain, Peak Hold, and Peak Memory
- Automated display precise flaw location
- Automated switch three staff gauge
- 100 independence setups, any criterion can be input freely, we can work in the scene without test block.
- Big memory of 300 A graph
- Gate and DAC alarm
- communication with pc is easy.
- The embedded software can be online updated.
- Li battery, continue working time up to 10 hours.
- Display freeze
Technical Specifications
| Temperature | -25 °F to 165 °F (-10 ℃ to 50 ℃) |
| Humidity | 20 % |
| Sound of speed | 1000 m/s to 1500 m/S |
| Range of gain | 0 dB to 100 dB |
| range | 0 in to 5.98 in (0 mm to 1000 mm) |
| Sound speed | 1000 m/s to 1500 m/s |
| Power supply | 7.4 V |
| Data save | 300 A-Scan images (including setting of instrument) |
| Overall dimension | 8.76 in x 4.78 in x 2.98 in (240 mm x 150 mm x 50 mm) |
| weight | 0.87 lb (1.6 kg) |
