Features
- Real time test result and graphic distribution of abnormal points each profile
- Adjustable sampling delay and amplification factor during the test
- High definition LCD screen for clear observation of waveform and wave speed
- User friendly touch screen interface for easy operation
- High capacity SD card for ample test data storage
- Built in high performance lithium battery for long fieldwork
- Various USB ports for data transmission and software updates
- Organized test data saved under project folders for reliable management
Technical Specifications
| Control Mode | Internal A8 Industrial control board |
| Screen | 5.7 in and high brightness TFT LCD screen |
| Operation Mode | Touch screen and button |
| Signal Collecting Mode | Automatic continuous collection |
| Accuracy | 0.025 μs |
| Time Range | ± 1677.7 ms |
| Dynamic Range | 154 dB |
| Amplifier Bandwidth | 3 kHz to 450 kHz |
| Receiver Sensitivity | ≤ 10 μ V |
| Gain Error | 0.5 dB |
| Emission Voltage | 65 V, 250 V, 500 V, 1000 V adjustable |
| Data Transmission | USB, Mini USB and Wi Fi |
| Power Supply | Built in lithium battery and 220 V AC / DC |
| Battery Time | > 5 hrs |
| Humidity | < 90 % RH |
| Temperature | 14 °F to 104 °F (-10 ℃ to + 40 ℃) |
| Size | 8.27 in × 5.87 in × 2.36 in (210 mm × 149 mm × 60 mm) |
| Weight | 3.02 Ib (1.36 kg) Lithium battery included |
