Technical Specifications
| Measuring | 0 in to 393 in (0 mm to 10000 mm) |
| Material Velocity | 1000 m/s to 15000 m/s |
| Gain | 0 dB to 130 dB |
| Working Frequency | 0.2 MHz to 20 MHz |
| Waveform memory | 500 |
| Channels | 500 |
| D-Delay | -20 μm to 3400 μm |
| P-delay | 0 μm to 99.99 μm |
| DAC | Yes |
| AVG | Yes |
| Built-in Standards | Yes |
| Vertical linear error | ≤3% |
| Horizontal linert error | ≤0.2% |
| Sensitivity Leavings | ≥62 dB |
| Dynamic range | ≥32dB |
| Recoring Time | 5 min |
| PC software | Yes |
| Humidity | 20% to 90% RH |
| Power | 7.4 V 4800 mAh |
| Working time | >10 hrs |
| Display | LED true color |
| Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Size | 9.37 in x 6.10 in x 1.81 in (238 mm x 155 mm x 46 mm) |
| Weight | 2.20 lb (1000g) |
