Features
- Automated calibration of transducer Zero Offset or velocity
- Automated gain, Peak Hold and Peak Memory
- Automated display precise flaw location (Depth d. level p, distances, amplitude, dB
- Automated switch (Depth d, level p, distance s)
- 100 independent set up, any criterion can be input freely, we can work in the scene
- without test block
- Big memory of 300 A graph
- Gate and DAC alarm
- Acoustic-Optical alarm
- The embedded software can be online updated
- Li battery, continue working time up to 10 hrs
Technical Specifications
| Measuring | 0 in to 393.7 in (0 mm to 10000 mm) |
| Material Velocity | 1000 m/s to 15000 m/s |
| Gain | 0 dB to 130 dB |
| Working Frequency | 0.2 MHz to 20 MHz |
| Waveform memory | 500 |
| Channels | 500 |
| D-Delay | -20 μm to 3400 μm |
| P-delay | 0 μm to 99.99 μm |
| DAC | Yes |
| AVG | Yes |
| Built-in Standards | Yes |
| Vertical linear error | ≤3％ |
| Horizontal linear error | ≤0.2％ |
| Sensitivity Leavings | ≥62 dB |
| Dynamic range | ≥32 dB |
| Recording Time | 5 mins |
| PC software | √ |
| Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Humidity | 20 ％ RH to 90 ％ RH |
| Power | 7.4 V 4800 mAh |
| Working time | ＞10 hrs |
| Display | LED true color |
| Size | 9.4 in x 6.1 in x 1.8 in (238 mm x 155 mm x 46 mm) |
| Weight | 2.2 lb (1 kg) |
