Technical Specifications
| Sound Velocity Range | 300 m/s to 20000 m/s |
| Gain Range | 0 dB to 120 dB |
| Dynamic Range | ≥ 30 dB |
| Signal Bandwidth | 0.5 MHz to 30 MHz |
| Vertical Linear Error | ≤ 3 % |
| Horizontal Linear Error | ≤ 0.1 % |
| Resolution | > 36 dB |
| Output | WIFI, USB 2.0, VGA |
| Control | Front panel sealed keyboard, shuttle, touch screen. |
| Power Supply | 8.4 V 10 mAh Lithium Battery |
| Working Time | Continuous working for 8 Hrs. |
| Relative Humidity | 20 % RH to 95 % RH |
| Ambient Temperature | 14 °F to 104 °F (-10 °C to 40 °C) (reference value) |
| Surplus Sensitivity | 60 dB 7.87 in (200 mm) |
| Display | 5.7 in bright true colour 640 × 480 daylight readable LCD, maximum A scan size 4.53 in x 3.40 in (115.2 mm × 86.4 mm) |
| Size | 10.47 in x 6.46 in x 1.89 in (266 mm × 164 mm × 48 mm) |
| Weight | About 2.75 Ib (1.25 kg) (including battery) |
