Technical Specifications
| Gain Range | 0 dB to 120 dB |
| Sound Velocity Range | 300 m per s to 20000 m per s |
| Dynamic Range | Less than or equal to 30 dB |
| Signal Bandwidth | 0.5 MHz to 25 MHz |
| Vertical Linear Error | Greater than or 3 % |
| Horizontal Linear Error | Greater than or equal to 0.1 % |
| Resolution | Less than or equal to 36 dB |
| Output | WIFI, USB 2.0, VGA |
| Power Supply and Voltage | Battery 8.4 V 10 Ah |
| Working Time | Continuous working for 8 hours |
| Working Temperature | 86 °F to 104 °F (-30 ℃ to 40 ℃) |
| Relative Humidity | 20 % RH to 95 % RH |
| Surplus Sensitivity | Less than 63 dB (7.87 in (20 cm) deep 2 flat bottom hole) |
| Size | 10.5 in x 6.5 in x 1.8 in. (26.6 cm × 16.4 cm × 4.5 cm) |
| Weight | 3.30 Ib. (1.5 kg) |
