Technical Specifications
| Test Scope | HRC: 20 to 70 HRB:41 to 100 HRA:61 to 85.6 HV:80 to 1599 HB:85 to 650 Tensile strength: 255 to 2180 N or mm2 |
| Test Direction | Support 360° and make the test head and the surface of the tested object 90°for testing |
| Hardness Unit | HB or HRC or HV or HRA or HRB or HS or MPA |
| Battery | 4.2 V, 4800 Mah Rechargeable battery |
| Endurance | It can be used continuously for 10 hr. when fully charged without turning on the backlight |
| Executive Standard | ASTME 140 2005: DIN 18265: GB or T1172 1999 |
| Storage | It can store 1000 groups x 20 test data |
| Test Head Size | 0.86 in x 6.02 in (22 mm x 153 mm) |
| Charging Time | Fully charged for 8 hr and each charging time shall not be less than 4 hr |
| Test Result | Measure multiple points to find the average value |
| Host Size | 6.3 in x 3.1 in x 1.22 in (162 mm x 81 mm x 31 mm) |
