Features
- OTDR (can measure active fiber)
- Optical Light Source
- Optical Power Meter
- Visual Fault Locator
- LED Light
Technical Specifications
| Wavelength | 1550 nm ±20 nm |
| Dynamic Range | 20 dB |
| Event Blind Zone | 9.84 ft (3 m) |
| ATT Blind Zone | 39.3 ft (12 m) |
| Test Range | 0.06 mi to 49.7 mi (0.1 km to 80 km) |
| Pulse Width | 5 ns to 20 us |
| Measurement Time | 5 s to 180 s |
| Sampling Points | 8 k |
| Measurement Mode | Real time, average, automatic |
| Input Light Detection | Support |
| OPM | +26 dBm to -50dBm, 850 nm or 1300 nm or 1310 nm or 1490 nm or 1550 nm or 1625 nm |
| VFL | 10 mW, 0.09 in (2.5 mm) universal connector |
| LCD | 3.5 in (2.54 cm) highdefinition touch screen |
| Working Temperature | 32 °F to 122 °F (0 ℃ to 50 ℃) |
