| Wavelength (±20 nm) |
1310 nm or 1550 nm |
| Dynamic Range |
24 dB or 24dB, 28 dB or 28dB |
| Rang of Use |
Single mode fiber |
| Dead Zone |
EDZ: 16.4 ft (5 m)EDZ: 11.4 ft (3.5 m); ADZ: 42.6 ft (13 m) |
| Connector |
FC or PC (Interchangeable SC, ST) |
| Distance Measure Accuracy |
± (3.2 ft (1 m) + 5×10-5×Distance + sampling space) |
| Attenuation Detect Accuracy |
±0.05 dB or dB |
| Reflection Detect Accuracy |
±4 dB |
| Data Storage |
1000 records |
| Connectivity |
RS 232 USB |
| Power Supply |
NiMH Rechargeable Battery or AC Adapter |
| Battery Life |
10 hrs continuous operation or 20 hrs standby |
| Operating Temperature |
14 °F to 122 °F (-10 ℃ to +50 ℃) |
| Storage Temperature |
-4 °F to 158 °F (-20 °C to 70 °C) |
| Relative Humidity |
0% to 95% (non condensing) |
| Weight |
2.20 lb (1 kg) |
| Dimensions (H x W x T) |
8.7 in × 4.3 in × 2.7 in (220 mm × 110 mm × 70 mm) |
