Technical Specification
| Output Flow | 450 ml/min (Hydrogen and Oxygen Mix) |
| Hydrogen Output Flow | 300 ml/min (Hydrogen Only) |
| Circulating Volume | <60 ml/min |
| Cycle Mode | Natural Cycle |
| Hydrogen Purity | 99.99% |
| Electrolysis | Water Electrolysis |
| Max Pressure | 0.5 MPa |
| TDR Anode Water | ≤1 PPM |
| Constant Current | 15 A |
| Constant Current Voltage | 8 V |
| Single Cell Voltage | 1.75 V to 2.5 V |
| Circulating Water Temperature | 77 ℉ to 113 ℉ (25 ℃ to 45 ℃) |
| Size | 2.83 in x 1.64 in x 2.75 in (72 mm x 41.9 mm x 70 mm) |
| Weight | 1.32 lb (0.6 kg) |
