| Weighing Accuracy |
0.00018 oz (0.005 g) |
| Load cell |
Strain sensor |
| Readability |
0.01% |
| Principle |
Thermal weight loss |
| Weighing Range |
4.23 oz (120 g) |
| Calibration Method |
External weight calibration, 3.53 oz (100 g) weight |
| Heating Method |
Ring halogen lamp heating |
| Heating Power |
500 W |
| Temperature Sensor |
High precision ultra fine platinum and rhodium temperature sensor |
| Display Mode |
Moisture content, solid content, drying rate, weight after drying, moisture regain, real-time temperature, graph |
| Shutdown Mode |
Automatic, timing, manual |
| Time Setting |
0 min to 99 min, 1 min interval |
| Communication Interface |
Thermal printing, directly print out the moisture value and solid content . Standard RS 232 communication interface, which can be connected to PC, printer and other peripheral equipment |
| Temperature readability |
33.8 ℉ (1 ℃) |
| Heating temperature range |
104 ℉ to 320 ℉ (40 ℃ to 160 ℃) |
| Voltage |
220 V, 50 Hz, 110 V, 60 Hz |
| Sample Pan |
4.02 in (102 mm) stainless steel |
| Size |
12.20 in × 7.87 in × 8.07 in (310 mm × 200 mm × 205 mm) |
| Weight |
7.72 lb (3.5 kg) |
