| pH |
|
| Range |
-2.000 pH to 20.000pH |
| Accuracy |
±0.002 pH |
| Resolution |
0.1 pH, 0.01 pH, 0.001 pH, selectable |
| Calibration Points |
1 to 5 points |
| pH Buffer Options |
USA, NIST, DIN or Custom |
| mV |
|
| Range |
±1999.9 mV |
| Accuracy |
±0.2 mV |
| Resolution |
0.1 mV, 1 mV, selectable |
| Conductivity |
|
| Range |
0.01 µS/cm to 20 µS/cm, 200 µS/cm, 2000 µS/cm, 20 mS/cm, 200 mS/cm |
| Accuracy |
±0.5% F. S |
| Resolution |
0.001, 0.01, 0.1, 1 |
| Calibration Points |
1 to 5 points |
| Calibration Solutions |
10 µS/cm, 84 µS/cm, 1413 µS/cm, 12.88 mS/cm, 111.8 mS/cm |
| Temperature Coefficient |
32 °F to 50 °F (0% to 10.0%/°C) |
| Compensation Modes |
Linear or Pure water |
| Cell Constant |
K=0.1, 1, 10 or Custom |
| Reference Temperature |
68 °F or 77 °F (20 °C or 25 °C) |
| TDS |
|
| Range |
0 ppt to 10 ppt, 100 ppt, 1000 ppm, 10 ppt, 100 ppt (Max. 200 ppt) |
| Accuracy |
±1% F. S |
| Resolution |
0.01, 0.1, 1 |
| TDS Factor |
0.1 to 1.0 (Default 0.5) |
| Temperature |
|
| Range |
32 °F to 221 °F (0 °C to 105 °C) |
| Accuracy |
32.9 °F (±0.5 °C) |
| Resolution |
0.1 °F (0.1 °C) |
| Calibration Points |
1 point |
| Calibration Range |
Measured value 50 °F (±10 °C) |
| General |
|
| Temperature Compensation |
32 °F to 212 °F (0 °C to 100 °C) Manual or Automatic |
| Data Hold |
Manual or Auto-Endpoint |
| Stability Criteria |
Low or High |
| Calibration Due Alarm |
1 to 31 days or off |
| Reset Function |
Yes |
| Memory |
Stores up to 500 data sets |
| Output |
USB communication interface |
| Connector |
BNC, 6-pin mini plug |
| Display |
LCD |
| Power |
DC 5 V, using AC adapters, 220 V AC/50 Hz |
| Dimensions |
8.27 in × 7.40 in × 2.36 in (210 mm × 188 mm x 60 mm) |
| Weight |
3.30 lb. (1.5 kg) |
