Features
- Automated calibration of transducer Zero Offset and Velocity
- Automated gain, Peak Hold, and Peak Memory
- Automated switch between Depth, level, and distance parameters
- Large memory with storage for 300 A scan graphs
- Gate and DAC alarm, as well as Acoustic Optical alarm
- RS 232/USB port for easy PC connectivity
- Embedded software can be updated online
- Long lasting Li battery with up to 10 hours of continuous operation
- Display freeze function
- Automated echo degree calculation
- Angles and K value adjustment
- Lock and unlock system parameter functions
- Electronic clock calendar
- Two gates setting with alarm indication
- High speed capture with minimal noise
- DAC and AVG curve generation
- Automated flaw size calculation with wide bottom AVG function
Technical Specifications
| Gain | 0 dB to 100 dB | |
| D Delay | -20 µs to + 3400 µs | |
| P Delay | 0 µs to 99.99 µs | |
| Material Velocity | 1000 m/s to 9999 m/s | |
| Humidity | 20 % to 90 % RH | |
| Power | 7.4 V 4800 mAh | |
| Working Time | > 8 Hrs | |
| Display | LED true colour | |
| Temperature | -4 ℉ to 122 ℉ (-20 ℃ to 50 ℃) | |
| Measuring Range | 0 in to 236.22 in (0 mm to 6000 mm) | |
| Resolution | 0.1 in x 0.2 in 3.94 in (0.1 mm x 2.5 mm x 100 mm)0.1 in to 3.94 in (1 mm to 100 mm) | |
| Size | 9.37 in x 6.30 in x 1.97 in (238 mm x 160 mm x 50 mm) | |
| Weight | 2.20 lb (1.0 kg) |
