Features
- Supports 9.95 Gb/s to 10.5 Gb/s bit rates
- Power dissipation <2.0 W
- Commercial temperature range: 23 °F to 167 °F (- 5 °C to 75 °C)
- RoHS-6 Compliant
- Hot-pluggable XFP footprint
- Maximum link length of 49.70 mi (80 km)
- Cooled CWDM EML
- APD Receiver
- Full Duplex LC connector
- No Reference Clock required
- Built-in digital diagnostic functions
- Standard bail release mechanism
Technical Specifications
| Connector Type | Dual LC |
| Fiber Type | SMF |
| Data Rate | 10 Gbps |
| Wavelength | 1470 nm to 1570 nm |
| Tx Power | 0 db to 5.5 db |
| Rx Sensitivity | ≤-23 db |
| Distance | 49.70 mi (80 km) |
