Features
- ITU-T DWDM grid wavelengths
- Data rate selectable ≤4.25 Gbps or 9.95 Gbps to 11.3 Gbps bit rates
- Temperature Stabilized DWDM DFB Transmitter
- Multi channels optional
- Low Power Dissipation 1.5 W Maximum
- Operating Case Temperature 23 °F to 158 °F (-5 °C to 70 °C)
- Single 3.3 V power supply
- Diagnostic Performance Monitoring of module temperature
- Diagnostic Performance Monitoring of module temperature
- receive optical power
- RoHS compliant and lead free
Technical Specifications
| Use | FTTX |
| Working Rate | 10 G |
| Connector Type | LC Dual |
| OEM | Available |
| Wavelength | 1559.79 nm |
| Reach Distance | 49.70 mi (80 KM) |
| Operating temperature | 32 °F to 158 °F (0 °C to 70 °C) |
