Features
- Up to 11.1 Gbps Data Links
- Up to 20 km transmission on SMF
- Power dissipation <1.5 W
- 1270 nm DFB laser and PIN receiver
- 2 – wire interface with integrated Digital Diagnostic monitoring
- EEPROM with Serial ID Functionality
- Hot-pluggable SFP+ footprint
- Compliant with SFP+ MSA with LC connector
- Single 3.3 V Power Supply
- Case operating temperature 32 ºF to 158 ºF (0 ºC to 70 ºC)
Technical Specifications
| Input Differential Impedance | 90 Ω to 110 Ω |
| Average Launch Optical Power | -8.2 dBm to 0.5 dBm |
| Optical modulation amplitude | -5.2 dBm |
| Extinction Ratio | 3.5 dB |
| Optical Wavelength | 1260 nm to 1355 nm |
| Side mode Suppression Ratio | 30 dB |
| Relative Intensity Noise | -130 dB/ Hz |
| Optical Return Loss | 12 dB |
| Power Supply | 3.3 V |
| Power Dissipation | 1.5 W |
| Distance | 20 km |
| Data Rate | 11.1 Gbps |
| Temperature | 32 ºF to 158 ºF (0 ºC to 70 ºC) Error: Contact form not found. |
