| Applicable Fiber |
SM (G.652), MM (G.651), DS (G.653), NZDS (G.655), others (including G.657) |
| Diameter Of Cladding |
80 μm to 150 μm |
| Diameter Of Coating |
160 μm to 900 μm |
| Typical Splice Loss |
SM:0.02 dB, MM:0.01 dB, DS:0.04 dB, NZDS:0.04 dB |
| Return Loss |
> 60 db. |
| Fiber Cleaved Length |
0.39 in to 0.63 in (10 mm to 16 mm) (coating diameter < 250 μm), 0.63 in (16 mm) (coating diameter: 250 μm to 1000 μm ) |
| Splicing Program |
40 groups |
| Operate Mode |
Manual, Automatic |
| Auto-heating |
Available |
| Typical Splicing Time |
6 s |
| Tube Heating Time |
20 s for 2.36 in (60 mm) and 1.57 in (40 mm) shrinkable sleeves |
| Fiber View Magnification |
250 x (X or Y view), 125 x (X and Y view) |
| Viewing Method and Display |
2 CMOS cameras, 4.3 in (10.92 cm) color LCD monitor |
| Storage Of Splice Result |
4000 results |
| Loss Evaluation |
Available |
| Tension Test |
1.8 N to 2.2 N |
| Interface |
GUI menu interface, easier operation |
| Battery Capacity |
5200 mAh Li-battery, typical 250 cycles (splice and tube heat) |
| Power Supply |
Adaptor, input: AC 100 V to 240 V (50 Hz or 60 Hz), output: DC 11 V to 13.5 V |
| Electrode Life |
More than 4000 ARC discharges, can be replaced conveniently |
| Terminals |
USB 2.0 port, for uploading splice results and upgrading software |
| Operating Condition |
Altitude: 0 mi to 3.011 mi (0 m to 5000 m), Humidity: 0 % to 95 %, Temperature:14 ° F to 122 ° F (-10 ℃ to +50 ℃); Wind speed: max 15m/s |
| Dimension |
6.3 in x 5.35 in x 5.51 in (160 mm x 136 mm x 140 mm) |
| Weight |
4.63 lb. (2.10 kg) including battery |
