Features
- Dual-wavelength 1310/1550nm or single 1310/1550/1610/1625/1650nm options
- Measurement distance up to 80km for long-haul fiber testing
- Capacitive touchscreen with fast response and key/touch operation
- Test records saved in SOR format for reliable data storage
- Integrated OTDR, Event Map, Optical Power Meter, VFL, and Optical Loss Test
- Optional RJ45 tracker for advanced cable testing
- USB and TF card interfaces for easy data export
- Quick startup, ready to test in just 2 seconds
- Editable file naming with keyboard input
- Supports firmware upgrades for extended functionality
Technical Specifications
| Specification | Details |
| Type | OTDR |
| Wavelength | 1550 ± 20nm (Dual: 1310 or 1550nm, or optional single 1310 or 1550 or 1610 or 1625 or 1650nm) |
| Measurement Distance | 2.304 Ft (Up to 80km) |
| Loss Resolution | 0.01dB |
| Loss Threshold | 0.2dB |
| Attenuation Zone | 10m |
| Display | Capacitive touchscreen, key + touch operation |
| Data Storage Format | SOR |
| Interfaces | USB, TF card |
| Functions | OTDR, Event Map, OPM, OLS, VFL, Optical Loss Test, RJ45 Sequence, Flashlight |
| Optional Function | RJ45 Tracker |
