Key Features
- Portable
- Durable
- Dependable
- The device two fully independent gates that offer a wide range of measurements
- Suitable for large work pieces and in high-resolution measurements
- Long battery life
- USB compatible with a high-speed communication port
Technical Specifications
| Display | 640 X 480 pixels |
| Range | 9999mm in steel (393.66 in) |
| Pulse Energy | 200V – 600V |
| Pulse width tunable from | 0.1µ S to 0.5 µ S |
| Pulse Repetition Frequency | 10 Hz to 1kHz in 1Hz increments |
| Damping | 68Ω100Ω150Ω and 500Ω |
| Test Modes | Pulse echo, dual and thru-transmission |
| sampling speed | 160 MHz |
| Rectification | Positive Half wave, Negative Half wave, Full wave and RF |
| Analog Bandwidth | 0.5MHz to 15MHz |
| Gain | 0 dB to 110 dB |
