Key Features
- Automated transducer calibration with Zero offset and /or velocity
- Automated gain with Peak Hold and Peak Memory
- Automated Peak Hold and Peak Memory gain
- Precision flaw locator
- Automated switch with three staff gauge – D-Level, P-Distance, Depth
- Huge memory with 300 A graph
- Acoustic-Optical alarm
- USB compatible
- Software included that can be updated online.
- Automated echo degree
- Angles and K-Value
- Functions of the system parameters is secured and could be locked by an authorized user
- Auto- shut off when the device is not used for a period of time
- Clock and calendar display
- Solid metal housing
- Readable in all angles
- Powerful pc software and reports can be exported to excel
Technical Specifications
| Designation | Technical Data |
| Range of scanning | Range of scanning (mm)：0～10000 (0~ 393.7in) |
| D-delay (ms) | D-delay (ms)：-20～+3400 |
| P-delay (ms) | P-delay：0.0～99.99 |
| MTLVEL（m/s） | MTLVEL：1000～15000 |
| Frequency Range (MHz) | 0.5~15 |
| Gain adjustment (dB) | 0～120 |
| Reject | 0%～80% of screen height, step: 1% |
| Vertical linear error | Vertical linear error is not more than 3% |
| Horizontal linear error | Not more than 0.2% in the scanning range |
| Sensitivity Leavings | ≥62 dB |
| Dynamic range | ≥34dB |
| A-Scan display area | Full screen or local
A-Scan display freezing and de-freezing A-Scan filling |
| Data save | 300 A-Scan images (including setting of instrument) |
| Standard communication interface with PC | RS232/USB |
| Measuring unit | mm/inch |
| Battery | Li battery 7.4V 4800mAh |
| Power adaptor | Input 100V～240V/50Hz～60Hz
Output 9VDC/1.5A |
| Working temperature | -10℃～50℃ (14°F ~ 122°F) |
| Working humidity | 20%～90% |
| Port type | BNC / LEMO |
| Overall dimension | 240×150×50mm (9.4 X 5.9 X 1.9 in) |
| Weight (kg) | 1.6 |
