Overview
Emissions And Stack compact peristaltic pump offers reliable dosing for food, beverage, and cosmetic applications including syrup, wine, detergent, and oil transfer. It features multiple motor options for varied flow requirements with forward and reverse operation. Designed for food-grade safety, it supports viscous liquid handling with smooth flow. Its quick disassembly and easy installation ensure convenient maintenance and durability.
Features
- Food grade design for safe liquid transfer
- Adjustable flow rate up to 3095 ml/min
- Multiple motor options: stepper, DC, planetary gear
- Straight inlet and outlet for efficient flow
- Supports viscous fluids like syrup, oil, and shampoo
- Quick disassembly with easy pressure block installation
- Forward and reverse operation with precise metering
- Strong suction capability for smooth dosing
Technical specifications
| Pump Type | Peristaltic Pump |
| Flow Rate | Up to 3095 mL/min |
| Flow Direction | Forward / Reverse |
| Pressure Range | Up to 1.7 bar |
| Outlet Pressure | ≤0.17 MPa |
| Outlet Size | ID 7.9 mm |
| Drive Options | Stepper motor, DC gear motor, DC planetary motor |
| Motor Voltage | 12V DC / 24V DC |
| Motor Current | 12V: 6A / 4A, 24V: 3A / 2A / 4A |
| Motor Power | ≤24W / ≤36W / ≤60W |
| Horsepower | 32W |
| Motor Speed | 150 – 507 rpm (depending on type) |
| Flow Rates at 24# Tubing | 625, 1190, 2030, 535, 1045, 1065 ml/min |
| Flow Rates at 35# Tubing | 940, 1880, 3095, 805, 1590, 1600 ml/min |
| Roller Count | 3 rollers |
| Main Materials | Polyamide support & base, Polyacetal wheels |
| Fluid Compatibility | Food, beverages, detergents, cosmetics |
| Inlet / Outlet Type | Straight connection |
| Special Functions | Start/Stop, speed adjustment, forward/reverse |
| Features | Quick disassembly, easy tube replacement |
| Control Method | Manual or external driver |
| Applications | Food, beverage, automotive, pharmaceutical, cleaning |
| Noise Level | Low operating noise |
| Suction Power | Enhanced for viscous liquids |
| Housing | Durable food-grade plastics |
| Safety | Stable and reliable performance |
| Operating Temperature | 0 – 60 °C / 32 – 140 °F |
| Weight | 607g – 910g (depending on type) |
