Features
- Dual or single wavelength options: 1310/1550nm / 1610/1625/1650nm
- Long measurement distance up to 80km
- Capacitive touchscreen with fast response and key input support
- Saves test records in SOR format for easy data export
- Multifunction: OTDR, Event Map, OPM, OLS, VFL, Optical Loss Test, RJ45 sequence tester
- Optional RJ45 tracker
- File naming and editing supported via keyboard input
- USB and TF card interface for convenient curve data export
- Quick 2-second startup time
- User-upgradeable firmware
Technical Specifications
| Attribute | Specification |
| Type | OTDR |
| Wavelength | 1310/1550nm (±20nm) / optional others |
| Measurement Distance | Up to 80km |
| Loss Resolution | 0.01dB |
| Loss Threshold | 0.2dB |
| Attenuation Zone | 10m |
| Display | Capacitive touchscreen + key input |
| Test Record Format | SOR |
| Standard Functions | OTDR, Event Map, OPM, OLS, VFL, Loss Test, RJ45 sequence |
| Optional Functions | RJ45 Tracker |
| Data Interfaces | USB, TF card |
