Features
- 650nm red light with 10mW output, ideal for identifying fiber breaks and faults
- Effective range of up to 10km for a wide variety of fiber testing tasks
- Simple on/off switch for quick operation in the field or workshop
- Compatible with standard multi-core fiber (core diameter 1.0 mm – 2.4 mm)
- Sturdy plastic housing built to handle tough environments and daily use
- Compact, lightweight design makes it easy to carry and operate in tight spaces
- High vibration resistance for dependable performance in demanding conditions
- Designed for technicians working with FTTH and other fiber optic networks
Technical Specifications
| Type | Visual Fault Locator Pen |
| Light Source | 650 nm red laser |
| Output Power | 10 mW |
| Detection Range | 6.21 mi (10 km) |
| Applicable Use | FTTH or IP fiber networks |
| Fiber Compatibility | 1.0 mm to 2.4 mm core diameter |
| Operating Mode | Continuous or pulse |
| Power Supply | 2 × AAA batteries |
| Housing Material | Durable plastic |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Weight | 1.41 oz (40 g) |
| Dimensions | 6.30 in x 0.59 in (160 mm x 15 mm) |
