Overview
Emissions And Stack Optic Power Meter is a multi-functional portable comprehensive test platform integrating E1, V.35, 10 or 100 or 1000 M or 10 G Ethernet, optical power meter test and other physical interfaces. It provides rich and powerful data network testing functions, easy and intuitive operation, full English display interface, direct display of test and statistical results; easy to carry, for engineering and maintenance personnel to carry out on-site installation, commissioning and maintenance to save a lot of time; multi-port, multi-functional integrated design, to improve engineering and maintenance efficiency, reduce costs to provide strong support.
Features
- Portable multi-port, multi-functional integrated design
- 7-inch color touchscreen
- Full English display interface, intuitive and convenient operation
- Test result storage and printing
- 5000 Am high capacity lithium battery
Technical specifications
| Display | High resolution 7 in color LCD with LED backlight |
| Storage | 1000 test results |
| Battery capacity | Lithium battery 5000 mAh, 12.6 V |
| Endurance time | About 4 hrs |
| Charging time | About 5 hrs |
| Charger specifications | 12.6 V or 3 A, 90 to 265 V AC, 50 to 60 Hz |
| Operating temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Storage temperature | -4 °F to 158 °F (-20°C to 70°C) |
| Working Humidity | 5 % to 90 % (Non-Condensing) |
| Dimension | 9.44 in × 6.30 in × 2.36 in (240 mm x 160 mm x 60 mm) |
