Features
- FTTx Passive Optical Network test
- Optical Port serial connection
- Handheld design
- P or F threshold test mode and normal test mode
- Large storage capacity
- Humanized design
Technical Specifications
| Sensor Type | InGaAs |
| Isolation Rate | |
| 1310 nm | 1490 nm > 40 dB, 1550 nm > 40 dB |
| 1490 nm | 1310 nm > 40 dB, 1550 nm > 30 dB |
| 1550 nm | 1310 nm > 40 dB, 1490 nm > 30 dB |
| Insertion Loss | < 1.5 dB |
| Test Range | |
| 1310 nm | -40 dBm to +10 dBm |
| 1490 nm | -50 dBm to +15 dBm |
| 1550 nm | -50 dBm to +20 dBm |
| Broadband | |
| 1310 nm | 1260 nm to 1360 nm |
| 1490 nm | 1480 nm to 1500 nm |
| 1550 nm | 1539 nm to 1565 nm |
| Accuracy | 0.5 dB ± 1 nW at 1550 nm |
| Resolution | 0.01 dB |
| Threshold | 10 groups (configured via PC software) |
| Data Storage | 1000 |
| Communication Port | USB port |
| Power Supply | 4 x Ni-MH AA battery |
| External Power Supply | 12 V AC or DC adapter |
| Accessories | Power adapter, USB cable, 2 FC adapter, 2 SC adapter, 3 ceramic sleeves, 4Ni-MH AA battery, Test report, Quick guide, Carrying bag |
| Use | FTTX installation |
| Certification | RoHS, CE |
| Adapter | FC or PC and SC or PC |
| Data Storage | 1000 S |
| Dimension | 7.48 in × 4.13 in × 2.17 in (190 mm × 105 mm × 55 mm) |
| Weight | 1.53 lb (700 g) |
